Mach 7 Complete Upright Vacuum Cleaner

U90-M7-C

User guides (click here to download)

Issues
Checks
Actions

How do I clean the dirt container?

Emptying and cleaning the dirt container

 Press the button on the front of the machine to release the dirt container

 Remove the dirt container

 Release the dirt from the dirt container

 Turn the lid anti-clockwise

 Lift the lid and separator out of the dirt container and brush with a soft brush to remove any debris

How do I clear a blockage in the hose?

Clearing a blockage

 Visually check the clear duct (A) on the back of the machine. If there is an obstruction, remove the 5 screws to access

 Remove the hose from the machine and push something through (like a broom handle) to clear any obstruction

How do I change the brushbar?

Accessing the belt and brushbar

 Switch the machine off and unplug from the wall socket

 Remove the 6 screws underneath the machine and lift the brushbar cover to remove

 Lift the brushbar to remove

How do I clean the post-motor filter?

Cleaning the post-motor filter

 Pull the filter frame out of the machine and tap against the side of a bin. DO NOT WASH

How do I clean the pre-motor filter?

Cleaning the pre-motor filter

 Press the button on the front of the machine to release the dirt container

 Slide across the latch to remove the frame and filter

Tap the filter against the side of a bin

Rinse the filter under the tap (no detergent)

Allow 24 hours to air dry

Specifications

Power

Multi-cyclonic

Air Watts

N/A

Variable Power

No

Capacity

0.00 litres

TurboTool

No

Cord

8.50 metres

Filters

Antibacterial HEPA

Hose

3.50 metres

Suitable for hard floors

No

Weight

10.70 kg

Guarantee

6 year guarantee

Other tools included

No

Part number

1-1-129268-00

Energy Efficiency Overall Rating

N/A

Depth

N/A

Height

N/A

Width

N/A
The Mach 7 Complete bagless upright vacuum cleaner has WindTunnel technology that traps dirt effectively to provide excellent dust pick-up. This powerful multi cyclonic upright has an extra stretch hose so you can clean right to the top of your staircase. Its anti-bacterial HEPA filter means it's a good choice for allergy sufferers, and automatic cord rewind provides easy storage of the power cable inside the machine. Ideal for homes with pets, the Mach 7 has a TurboTool for shifting stubborn pet hair, that's also great for cleaning stairs, upholstery and car interiors. Other accessories include a hard floor tool, crevice tool, upholstery tool and dusting brush and the Vax 6 year guarantee provides total peace of mind.
